A fastener material certificate records evidence about the material and inspection documents supplied with a production lot. Under EN 10204, the certificate type identifies the kind of inspection evidence and who validates it. Type 2.2 is a test report based on non-specific inspection, while Type 3.1 reports results from specific inspection and is validated by the manufacturer’s authorized inspection representative who is independent of production. The right choice depends on the purchase order, product standard, regulatory code, and traceability risk. A certificate type alone does not prove every fastener dimension, process step, or assembled-joint performance.
BS EN 10204:2004 is the European standard for types of inspection documents for metallic products. It distinguishes documents based on non-specific and specific inspection and sets expectations for validation and transmission. It does not replace the fastener’s dimensional, mechanical, coating, marking, or testing requirements from the product standard and drawing.
Type 2.2 test results may be from the manufacturer’s non-specific inspection process and are not necessarily tied to the exact material heat or supplied lot. Type 3.1 is specific to the inspection results for the delivered material and is validated by an authorized inspection representative independent of manufacturing. Type 3.2 adds validation by a customer-appointed or official third party. Confirm precise definitions in the current applicable standard and contractual requirements rather than relying on a supplier’s shortened description.
The key distinction is the basis and independence of the inspection. A 2.2 document states conformity to the order and can include results from non-specific inspection. A 3.1 document reports results from specific inspection and is validated by the manufacturer’s inspection representative who is independent from the manufacturing department. A 3.1 does not automatically include an external witness; that additional role is associated with a 3.2 inspection document.
Neither type should be requested automatically without considering the risk and purchase terms. A contract that requires 3.1 makes that document part of acceptance. A supplier may be unable to retroactively change a 2.2 record to 3.1 if the required batch-specific test evidence was not retained or produced. Define the certificate type before order placement and confirm it appears on the purchase order, drawing, and delivery requirement.
| Document type | Inspection basis | Validation | Typical purchaser check |
|---|---|---|---|
| 2.1 Declaration of compliance | Manufacturer declares conformity to the order without test results | Manufacturer | Confirm whether a declaration alone satisfies the purchase requirement |
| 2.2 Test report | Conformity with results from non-specific inspection | Manufacturer | Check that the document is not being represented as batch-specific 3.1 evidence |
| 3.1 Inspection certificate | Conformity and results from specific inspection of the supplied material | Manufacturer’s authorized representative independent from production | Match heat or lot, product, specification, delivery, and inspection results |
| 3.2 Inspection certificate | Specific inspection with additional independent validation or witness | Manufacturer and customer-appointed or official representative | Confirm witness identity, scope, signatures, and required test records |
The table summarizes common distinctions. The standard text and the order govern the exact document content and acceptance rule.
Start with the manufacturer, certificate number, issue date, purchaser, purchase order, delivery note, and product description. Confirm material designation, product standard, heat or lot number, form, dimensions, finish, and any treatment stated on the certificate. The unique identifier should connect the report to the physical fastener packaging or the supplier’s traceability records.
Review chemical analysis and mechanical test results against the actual specification and its edition. Do not assume every reported value applies to a finished bolt or screw after forming, heat treatment, coating, or machining. A bar-stock certificate may describe incoming material rather than the finished fastener’s final mechanical properties. Verify which tests the fastener standard requires and which manufacturing stage the records cover.
Check authorization and validation. Confirm the signatory role matches the certificate type. Ensure amendments, deviations, or exceptions are visible and approved. If a certificate is digitally issued, retain the original file and any validation metadata required by the quality system. A scanned signature alone may not establish the document’s relationship to a delivered batch.
Traceability requires the certificate’s material heat or lot to match the marks, labels, packaging, and supplier production record for the parts delivered. If a shipment contains multiple heats or lots, keep the separation clear through receiving, storage, and production. Avoid mixing bins after opening cartons unless the lot identity is retained at the sub-container level.
When fasteners undergo secondary processes such as heat treatment, plating, coating, or sorting, preserve the chain between the original material and the finished lot. A material certificate does not document every downstream operation unless those operations and records are included. The fastener traceability guide covers lot records and supplier-to-assembly genealogy.
Check whether the certificate is tied to the delivered heat or only to representative production data. Compare the heat number on the certificate with the supplier’s material tag and receiving label, and make sure the purchase order, quantity, specification, and product form match. If the fastener manufacturer blends or splits lots during forming, plating, heat treatment, or sorting, request the process record that connects the incoming heat to the finished-lot identifier.
Also distinguish raw-material evidence from finished-fastener evidence. A steel bar report can document the incoming chemistry and selected mechanical results, but it does not by itself show the final bolt’s dimensions, thread condition, heat-treatment response, coating thickness, proof load, or marking. Request each record required by the applicable product standard, drawing, and quality plan. Keep the certificate, test report, first article, and inspection sample connected by part number, revision, heat, and production lot.
Do not silently treat a certificate without a heat number as a lot-specific record. If the supplier cannot map the report to the delivered package, hold the material for review and obtain written clarification or a corrected document. This is an evidence gap, even if the fastener itself looks correct.
A certificate and a first article inspection serve different purposes. The certificate documents material or inspection evidence at the specified level. A first article inspection compares production characteristics against the drawing and process requirements. It can include dimensions, thread gauges, material records, markings, coating, and functional features. Neither document replaces the other when both are required.
The ISO 898-1 standard specifies mechanical and physical properties for covered carbon- and alloy-steel bolts, screws, and studs. Its scope is not a universal material certificate format and it does not establish every property for every fastener type. Use the appropriate product standard and approved drawing. TNHO’s hex and square-head bolt product family illustrates relevant fastener geometry; the quotation defines the actual material, grade, finish, and documentation package.
For further review, see the fastener first article inspection checklist and the hex bolt grades guide. Provide those requirements on the RFQ so the supplier knows whether the request is for a material declaration, specific inspection certificate, dimensional report, or complete first article package.
Write the certificate type, product standard, material grade, test requirements, lot traceability, language, format, and delivery timing into the order. Identify whether the certificate must accompany each shipment, each heat, or each production lot. If a 3.2 third-party witness is needed, schedule it before production and define the witness scope.
At receiving, compare the certificate with the purchase order, packing list, package labels, material marking, and part identity. Record discrepancies and quarantine uncertain lots until quality or engineering approves disposition. Do not accept a visually plausible document if its heat number or product description does not match the delivered fasteners.
This industry training video reviews EN 10204 inspection-document types and the information they carry. It provides document-reading background; the purchase order and current standard determine acceptance.
Typical issues include a type 2.2 report presented as type 3.1, a heat number that does not match the material tag, a certificate for raw bar supplied as proof of finished-fastener properties, missing test results, unapproved deviations, and unclear downstream heat-treatment or coating records. Another risk is a certificate that names a generic material but omits the product form or dimension needed to determine which specification applies.
If a field is missing, ask for clarification or a corrected record before accepting the part. Avoid editing supplier certificates locally. Keep the original version and the approved disposition together in the quality record.
Type 2.2 is based on non-specific inspection and includes a test report. Type 3.1 is based on specific inspection for the supplied material and is validated by an authorized inspection representative independent from production. Check the current standard and order for exact scope.
Not necessarily. It documents the specified material inspection. Finished fastener dimensions, mechanical properties, coating, marking, and functional tests may require separate records under the product standard or drawing.
Match the manufacturer, product description, specification and revision, material grade, heat or lot, dimensions, purchase order, delivery record, test results, and required validation signature.
Use it when the contract, code, or risk assessment requires specific inspection with independent customer-appointed or official validation. Agree the witness scope and timing before manufacture.
